Home > Security Series > Surge Protector > Telephone Line Protector
SURGE PROTECTOR PRODUCTS

Features
  • Protect telecommunication network for telephone equipments or surveillance camera from lighting damage
  • Surge energt is fully suppressed(RJ-45) or absored(RJ-11)/ to protect devices
  • Automatic recovery characteristic provides repeated protection in lightning frequent environment
  • Suitable for any severe applications
  • Modular Jack connector facilitates the installation
  • Conform to ANSI C62.45 and IEC61000-4-5 standard
  • CE approval.


Model No.
AISA-004-R11
Signal Attenuation
< 15dB
Withstand Voltage
---
Impulse Limit Voltage
12KV (10/700µs) / 12KV(COMBI)
Breakdown Voltage
184 ~ 276 Vmax
Max. Surge Discharge
20KA (8/20 µs)
Max. Current Loading
120 mA
Response Time
< 1 µs
Internal Impedance
< 120 O
Application
XDSL / ADSL Under DC 230V data line
